Specifications
| eyepiece | WF10X / f20 |
| objective lens | Flat-field color difference objective: 4 ×/0.10, 10 ×/0.25, 40 ×/0.65, 100 ×/1.25 (oil) |
| Trinocular observation head | Hinged 30 ° tilt |
| pupil distance | 55mm-75mm |
| Mechanical barrel length | 160mm |
| Total magnification | 40X~1000X |
| converter | Four hole converter |
| stage | Double-layer mechanical mobile (size: 160mmX140mm, moving range: 75mmX50mm) |
| Focusing system | Coarse micro-motion coaxial focusing, coarse elastic adjustable, with locking and limiting device plate, micro-motion grid value: 2μm |
| Fluorescence filter set | B (blue excitation) 420~485nm, G (green excitation) 460~550nm |
| Mercury lamp box | 100W/DC |
| Fluorescence device power box | AC: 110V or 220V |
| light source | 6V 20W halogen lamp, brightness adjustable |
| condenser | 1.25NA Abbe condenser, variable light bar |
| Instrument Gross Weight | 10kg |
| Instrument size | 21X50X54（cm） |
| Packaging Dimensions | 45X37X47（cm） |
Packing list
After-sales instructions
Warranty days: 365 days
All the equipment purchased in Shanghai Optical Instrument Factory No. 6 in the north and south tides, the original factory promises to be free of charge during the warranty period. Accessories and improper use are excluded.
