Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation head | Hinged binocular lens barrel, 30 ° tilt; triocular lens barrel, adjustable pupil distance and diopter. |
| Eyepieces (large field of view) | WF10X(Φ18mm) |
| Standard objective (long distance flat field color difference objective) | PL L 10X/0.25 WD8.90mm；PL L 20X/0.40 WD3.75mm；PL L 40X/0.65 WD2.69mm；SP 100X/0.90 WD0.44mm （油） |
| converter | Ball internal positioning four-hole converter |
| Focusing system | Coarse fretting coaxial focusing, fine-tuning grid value: 0.002mm; stroke (from the focus of the surface of the stage): 30mm. Coarse elastic adjustable, with locking and limiting device |
| stage | Double-decked mechanical mobile (size: 180mmX150mm, moving range: 15mmX15mm) |
| lighting system | 6V 20W halogen lamp, adjustable luminance |
| Color filter | Yellow color filter, green color filter, blue color filter |
| Metallographic analysis system | JX2016 metallographic analysis software, 3 million camera device, 0.5X adapter mirror interface, micrometer |
