Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation head | Hinged binocular lens barrel, 45 ° tilt; pupil distance adjustment range 53~ 75mm |
| eyepiece | Flat field wide field eyepiece WF10X/22mm |
| Standard objective (infinity field objective) | PL L5X/0.12 BD WD9.70mm，PL L10X/0.25 BD WD9.30mm，PL L20X/0.40 BD WD7.2mm，PL L50X/0.70 BD WD2.50mm |
| converter | Ball internal positioning five-hole converter |
| Focusing system | Coarse fretting coaxial focusing, with locking device, fretting grid value: 2μm. |
| stage | Mechanical moving stage, Dimension (242 * 200mm), moving range (30 * 30mm) |
| circular stage | The maximum outer diameter is 130mm, and the minimum light diameter is less than 20mm. |
| lighting system | 12V50W halogen lamp, adjustable luminance |
| Polarizing device | Polarizer group, polarizer group |
| Color filter | With Frosted Glass, Yellow, Green and Blue Color Filters |
| Metallographic analysis system | JX2016 metallographic analysis software, 3 million camera device, 0.5X adapter mirror interface, micrometer |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31681/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
