Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation head | Trinocular observation tube, 45 ° tilt, hinge group can be 360 ° swirl/spin, fixed eyepiece tube, pupil distance adjustment range 50-75mm, two-speed splitting ratio: binocular: trinocular = 100:0 or 0:100 |
| eyepiece | High eye point and large field of view flat field eyepiece PL10X/22mm, adjustable visibility. |
| Infinite distance light and dark field objective | LMPL5X /0.15BD DIC WD9.0；LMPL10X/0.30BD DIC WD9.0；LMPL20X/0.45BD DIC WD3.4 |
| Infinite distance light and dark field objective | LMPLFL50X/0.55 BD WD7.5 |
| converter | Inner Positioned 5-Hole Open-Dark Field Converter (with DIC Slot), Built-in Magnification Sensors |
| rack | Reflection light and dark field gold camera holder, using low hand position coarse fine-tuning coaxial, coarse adjustment stroke 9mm, focal surface up 6.5mm, down 2.5mm, fine-tuning Accuracy 0.002mm, with elastic adjustment handwheel to prevent sliding |
| rack | With bright and dark field switching device, with variable field diaphragm and aperture diaphragm, the center can be adjusted; with color filter slot and polarizing device slot, with light source luminance indicator strip, with infrared sensing and objective lens magnification display function |
| stage | Three-layer mechanical mobile platform, Platform size: 240 (W) × 250 (L), moving range 50 × 50mm, two-way line-rail transmission, right-hand low-hand position control |
| lighting system | External wide Voltage transformer, input 100-240V, output 15V13.4A, 12V100W halogen lamp, continuous adjustable luminance |
| Polarizing device | Polarizer insert board, fixed polarizer insert board, 360 ° swirl/spin polarizer insert board |
| Color filter | LBD filter. |
| Metallographic analysis system | JX2018 metallographic analysis software, 5 million camera device, 0.5X adapter mirror interface, micrometer |
