Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation head | Hinged trinocular head, 45 ° tilt, pupil distance adjustment range: 54-75mm, unilateral visibility adjustment +/- 5 diopter split ratio: binocular 100%, binocular: trinocular = 80%: 20% |
| eyepiece | High eye point, ultra-wide field of view flat field eyepiece PL10X/22mm |
| objective lens | LMPL5X /0.15 WD10.8mm |
| converter | Internal positioning five-hole converter |
| mirror body | Coarse fine-tuning coaxial, coarse-tuning per turn: 38mm, fine-tuning per turn: 0.2 mm, focusing Accuracy: 0.002mm, with elastic adjustment device |
| workbench | Size 160X250mm |
| workbench | Metal stage plate (center hole φ 12mm), mechanical moving ruler, stroke 120 (X) * 78 (Y) mm, stage extension plate |
| Reflection Lighting source | Reflection Cora illuminator with variable aperture light bar and center adjustable field of view light bar, adaptive 100V~ 240V wide Voltage, 12V50W imported halogen lamp, center adjustable, continuous adjustable luminance |
| Polarizing device | The polarizer can be swirled/spun 360 degrees, and both the polarizer and the polarizer can be moved out of the light path |
| Color filter | Green color filter, blue color filter (φ 32mm) |
| Metallographic analysis system | JX2016 metallographic analysis software, 5 million camera device, 0.5X adapter mirror interface, micrometer |
