Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation head | Hinged trinocular, 30 ° tilt, 360 ° swirl/spin, adjustable visibility |
| eyepiece | High eye point large field of view flat field eyepiece PL10X/18mm |
| Long distance flat field color difference objective | LMPL5X /0.125 WD15.51mm；LMPL10X/0.25 WD8.7mm；LMPL50X/0.60 WD5.10mm |
| converter | Inner positioning four-hole converter |
| Focusing system | Low coaxial coarse fretting focusing frame, stroke 25mm, fine-tuning Accuracy 0.002mm, with coarse elastic adjustment device and random limit device, built-in 6V30W transmitted light illumination, Upper/Lower lighting switching |
| stage | Compound double-decked mechanical moving platform, table size 140 * 132mm, moving range: 76mmX50mm, Accuracy 0.1mm. |
| lighting system | Reflection Cora illumination, adaptive wide Voltage 100V-240V, 6V/30W halogen lamp, Light intensity continuously adjustable, with variable aperture diaphragm and field diaphragm, field diaphragm center adjustable |
| Color filter | Yellow, green, blue, matte color filters |
| Metallographic analysis system | JX2016 metallographic analysis software, 3 million camera device, 0.5X adapter mirror interface, micrometer |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31689/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
