Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation head | 30 ° tilt, infinity hinge tee observation cylinder, pupil distance adjustment: 54mm~ 75mm, visibility adjustment: +/- 5 diopters, two-speed split ratio R: T = 100:0 or 50:50 |
| eyepiece | High eye point large field of view flat field eyepiece PL10X/22mm |
| Infinity flat field objective | LMPL 5X /0.15 WD10.8mm；LMPL 10X/0.30 WD12.2mm；LMPL 20X/0.45 WD4.00mm；LMPL 50X/0.55 WD7.9mm |
| converter | Internal positioning five-hole converter |
| Focusing system | Transparent dual-use frame, low-hand coarse and micro coaxial focusing mechanism, coarse adjustment stroke 28mm, fine-tuning Accuracy 0.002mm. With adjustment elastic device to prevent sliding and random upper limit device. With platform position up and down adjustment mechanism, the maximum sample height 28mm, |
| stage | Double-decked mechanical moving platform, low hand position X, Y direction coaxial adjustment; platform area 175X145mm, moving range: 76X42mm can be equipped with anti-dual-use Glass platform |
| upper lighting | Adaptive wide Voltage 100V- 240V_AC50/60Hz, reflection lamp room, single high power 5WLED, warm color, Cora lighting, with field and aperture diaphragm, center adjustable, with oblique lighting device |
| Down lighting | Adaptive wide Voltage 100V-240V_AC50/60Hz, light room, single high power 5WLED, warm color |
| condenser | Shake-out color difference condenser for transmission (N. A0.9) with variable aperture diaphragm, adjustable center |
| Metallographic analysis system | JX2016 metallographic analysis software, 3 million camera device, 0.5X adapter mirror interface, micrometer |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31690/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
