Specifications
| Optical inspection system | Optical inspection system for color difference correction |
| observation head | Triple eyepiece, tilted 30 °, (built-in polarizer, switchable) |
| eyepiece | Large field of view WF10X (0019 18mm) |
| Standard objective (long distance flat field color difference objective) | PL L5X/0.12 WD15.5 mm；PL L10X/0.25 WD8.80mm；PL L40X/0.6 WD3.73 mm；PL L60X/0.75 WD1.34 mm |
| converter | Four holes (inward ball positioning) |
| Focusing system | Coarse fretting coaxial focusing, fretting grid value: 2μm, coarse elastic adjustable, with locking and limit device |
| stage | Double-decked mechanical mobile (size: 185mmX140mm, moving range: 75mmX50mm) |
| lighting system | 6V 20W, halogen lamp, luminance adjustable; emitter illuminator with field of view diaphragm, aperture diaphragm, polarizer. |
| Color filter | With Frosted Glass, Yellow, Green and Blue Color Filters |
| Metallographic analysis system | JX2016 metallographic analysis software, 3 million camera device, 0.5X adapter mirror interface, micrometer |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31691/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
