Specifications
| Measuring range | Ra: 0.025-12.5um |
| Display range | Ra 、 Rq: 0.005-16um; Rz 、 Ry 、 Rt 、 Rp 、 Rv 、 Rmax 、 R3z 、 R3y: 0.02-160um; Rs 、 Rsm 、 Rpk 、 Rvk: 1mm; Rmr: O-100% (% Rt); Rsk 、 Rku 、 Rpc 、 Mr1 、 Mr2: O-100% |
| range | ±20um、±40um、±80um |
| Highest display resolution | 0.001um |
| filter | RCGAuSSPC-RCD-P |
| Sampling length | 0.25mm,0.8mm,2.5mm |
| Evaluation length L | (1-5) l (optional) I is the sampling length |
| Maximum drive stroke | 17.5mm/0.7inch |
| Minimum drive stroke length | 1.3mm/0.052inch |
| Error of indication | ≤±10% |
| Indication of variability | ≤6% |
| Wireless communication distance | 10 meters |
| Instrument size | 135mmX45mmX42mm |
| File output method | Excel，word |
| Power Supply | lithium battery |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31706/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
