Specifications
| indentation rate | 0.01~0.70mm/s |
| Dimensions | 450*350*600mm |
| Net Weight | About 31kg |
| Stroke length | 0~12mm |
| Speed Accuracy | +/- 1% of the set speed |
| Stroke length Accuracy | +/- 0.01 mm or 0.2%, whichever is greater |
| Power Consumption | ≤80w |
| test panel width | ≤100mm |
| Maximum panel thickness - steel | 0.8mm |
| Maximum Panel Thickness - Aluminum | 1.2mm |
| Display | Blue screen 100 * 35mm, 193.64 pixels |
| security | Emergency button with integrated audible alarm |
