Specifications
| Detect gas | Br2 |
| Range | 0~10ppm |
| resolution | 0.01ppm |
| Expansion gas | Supports 1-5 Sensors, any combination |
| Humidity | Temperature detection range: -40~120 ℃, Humidity detection range: 0~100% RH |
| Sampling method | Pump suction |
| Linearity | ≤±1% |
| Zero drift | ≤ +/- 1% (F. S/year) |
| Repeatability | ≤±1% |
| detection Accuracy | ≤±3% |
| Response time | ≤20s(T90) |
| recovery time | ≤20s |
| Data storage | Real-time storage and timed storage can be set; a single channel can store 30,800 sets of data |
| Shell material | ABS+PC |
| Explosion-proof sign | ExdII CT4 (Intrinsically Safe Type) |
| Operating temperature | -30~60℃ |
| Environmental humidity | ≤ 95% RH, non-condensing |
| Protection level | IP65 |
| Power Supply | 4000mA rechargeable polymer battery |
| Operating Pressure | -30~100Kpa |
| Dimension | 220*85*55mm |
| Net Weight | 0.5 Kg |
Packing list
Gas detector X1, Dust Filter X1, Instrument case X1, manual, certificate, USB charger, calibration cover
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/31951/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
