Specifications
| Capacity selection | 500kg |
| Force Precision | <±0.5％ |
| monitor | Touch screen (with printing) |
| Force unit | Kg、lb、N |
| Frequency of data sampling | 200times/sec |
| force resolution | The maximum load is 1/+/- 25,000 yards, the inside and outside are not divided, and the whole process resolution remains unchanged |
| Load Sensors | Basic Configuration: Pull and Pressure Sensors (Maximum Load) |
| Effective test width | 150mm |
| Efficient stretching of space | 1200Mm (850mm with powerful pliers) |
| Test speed range | 100~500mm/min |
| Displacement error of indication | ±0.5％ |
| breakpoint ratio setting | 0~99%, users can set the appropriate break downtime according to different materials |
| Test bench Safety Devices | Up and down stroke limiting device |
| Overload protection | Exceeding the maximum load by 10%, the machine is automatically protected |
| Fixture configuration | A set of stretching fixtures |
| Dimensions | 550*400*1820mm |
| Host Weight | About 100Kg |
| Power supply Voltage | 220V/50Hz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32264/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
