Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~1300μm |
| margin of error | ±3% |
| Resolution | 1μm|0.01mm |
| Minimum measurement surface | Φ6mm |
| Minimum radius of curvature | Convex 1.5mm; Concave 25mm |
| thinnest substrate | 0.5mm(F)；0.3mm(N) |
| Test environment | Both magnetic and nonmagnetic substrates |
| probe | Built-in probe |
| Calibrated mode | Zero and multi-point calibrated (up to 4 points) |
| Measurement mode | Single and continuous |
| Unit display | um,mm aremils |
| statistical function | Average, MIN Minimum, MAX Maximum and standard deviation |
| Interface | USB port |
| Power Supply | 2 1.5V AAA batteries |
| Standards | ISO 2808 |
| system language | Chinese, English |
| Display screen | 128 * 128 dot matrix LCD display |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
| Machine Weight | 92g |
| Machine size | 110*53*24mm |
| alert | High/low alarm, an alarm icon will be displayed on the LCD when the limit is exceeded |
Packing list
Host x1, USB data cable x1, software x1, 1.5V AAA battery x2, NFe substrate x1, Fe substrate x1, Encasement box x1, foil sleeve x1
