Specifications
| Friction method | Reciprocating |
| Frictional contact form | line |
| Number of grinding heads | 1 |
| Friction Frequency | 0~2.5Hz |
| Test Travel | 12.7~50.8mm |
| Power supply Voltage | 230V，50~60Hz |
| Machine size | 1050*790*760mm |
| Machine Weight | 125kg |
| Noise level | ＜70dB |
| power consumption | 265w |
| gas source | 8bar±20% |
| operating temperature | 0~50℃ |
| Operating humidity | 0~90% RH (non-condensing) |
| Can diameter range | 53~84mm |
| Tank height range | 88~205mm |
| Can size | 150~1000ml |
| top pressure | 0~6bar |
| lateral pressure | 0~6bar |
| continuous test duration | 0~24h |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
