Specifications
| Probe tip | ruby |
| Measurement principle | Magnetic Induction + eddy Current |
| Probe position | Built-in integrated |
| Measurement range | 0~2000μm |
| Resolution | 0.1μm|1μm|0.01mm |
| margin of error | ±3% |
| Unit display | μm/mil |
| Measurement interval | 0.5s |
| Minimum measurement surface | Φ25mm |
| Minimum radius of curvature | Convex: 5mm/Concave: 25mm |
| Minimum substrate thickness | Fe:0.2mm / NFe:0.05mm |
| Display screen | 128 × 64 lattice low temperature resistant OLED |
| Power Supply | 2 1.5V AAA alkaline batteries |
| Operating temperature | -40℃ - 50℃ |
| Storage temperature | -50℃~60℃ |
| Host size | 101*62*28 mm |
| Weight | 79G (including battery) |
Packing list
Paint film instrument X1, Fe zero adjustment plate X1, NFe zero adjustment plate X1, standard sheet X1, manual X1, quality assurance card X1, certificate X1, cloth Encasement bag X1, 1.5V AAA alkaline battery X2
After-sales instructions
Warranty days: 365 days
1. If the instrument and equipment are not artificially caused by product quality problems, the manufacturer provides 1 year free warranty service;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32327/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
