Specifications
| Instrument level | 0.001 |
| Display | 5-Inch color touchscreen |
| Measurement mode | pH/mV(ORP)/Rel.mV |
| pH Measurement Range | -2.000~20.000pH |
| pH resolution | 0.001 |
| pH Accuracy | ±0.002 |
| mV range | -2000.00~2000.00mV |
| mV resolution | 0.01 |
| mV measurement Accuracy | +/- 0.1mV relative |
| Manual temperature range | -5.0~135.0 ℃ |
| Automatic temperature range | -5.0~135.0 ℃ |
| Resolution | 0.1℃ |
| Accuracy | ±0.1 ℃ |
| Calibrated | Support automatic temperature compensation, built-in 9 groups of 44 buffers, automatic identification user-defined support 1-9 point correction, can set 1-1000 hours correction reminder |
| data storage | 2000 sets of measurement data, 10 electrodes x 10 sets of calibration, in accordance with GLP specifications |
| output method | RS232, USB, optional printer |
| Power Supply | 9-12V/1A (external Power Supply) |
| pH input | BNC, impedance > 10e + 12Ω |
| Temperature transducer | NTC，30KΩ |
| endpoint mode | Manual/automatic/time, three options |
| extended functionality | Continuous measurement mode, dynamic Linear dispersion display: pH vs No./mV vs No. |
| Dimensions | 250*165*65mm |
| Scope of activity of the bracket | Height 320mm, radius 400mm or so, |
