Specifications
| Dimensions | 619*606*680 mm |
| Workbench range | X:300 Y:300 Z:100 mm（选配） |
| Platform plane Accuracy | ±5μm (100 mm) |
| Clearance control Accuracy | 2 μm |
| Speed range | 0-60 (X axis) 0-70 (Y axis) 0-40 (Z axis) mm/s |
| Substrate heating temperature | 0-180 ℃ |
| Temperature deviation | ±2 ℃ |
| Ink supply flow | 0.001-1 ml/s |
| Solvent system | Waterborne, oily, organic solvent based coatings |
| Applicable substrates | Glass, PET, CPI, aluminum foil and other flexible substrates |
| Substrate clamping method | Vacuum adsorption |
| Key control method | Touch screen control |
| Application process | Slit Application, ultrasonic lame plating, scraper scraping, bar roller painting (optional) |
| Application Film thickness range | 0.05-20 μm (thickness of dry film) depending on Application process and Printing ink |
| Application width | 10-200 mm depending on the choice of Application head |
| Application number | 1-10 The number of Applications can be freely set |
| Slit head inner surface linearity | ≤ 1.5 μm |
| Ultrasonic lame plating atomizing particle size | 15-40 μm |
| Lame plating width | 2-20 mm |
| Viscosity of liquid | ≤30 cps |
Packing list
Host X1, power cord X1, wrench X3, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
