Specifications
| test parameters | 10 AC resistors, 10 DC Voltages |
| Basic Precision | Resistance: 0.5% Voltage: 0.05% |
| Measurement range | Resistance: 0.01mΩ~ 33.000Ω Voltage: 0.00001V~ 60.000VDC |
| signal source | AC 1kHz, test current: < 150mA |
| range | Three-range automatic and manual |
| Test speed | Fast 10 ways/1 second, medium speed 10 ways/2 seconds, slow speed 10 ways/3 seconds |
| Show results | Direct reading, Delta ABS, delta%, theta, sorting result |
| MAX reading | Resistance: 3,0000 Voltage: 60,000 |
| correction | Short circuit clearing in full scale |
| comparator | RHI/RNG/RLO output VHI/VNG/VLO output absolute value tolerance +/- TOL sorting, percentage tolerance TOL sorting, sequential comparison sorting |
| trigger | Internal trigger, manual trigger, external trigger and remote trigger |
| interface | RS-232C interface Handler interface (PLC interface) |
| power requirements | Voltage: 195VAC~ 245VAC Frequency: 50Hz Power: 15VA |
| Size and Weight | External Dimensions (mm): 264 (W) x107 (H) x350 (D) Weight: 4kg |
| Accessories | ATL505 Kelvin test cable, ATL108 RS232 interface cable |
| Optional Accessories | ATL506A test probe ATL506 test watch rod |
| Miscellaneous | Test line damage detection True color TFT-LCD display, keypad lock and data retention function Internal flash memory and USB flash drive Data Logging |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
