Specifications
| function | Any two-axis simultaneous action, two-axis continuous action, random action (bandwidth can be set), sine wave (half-wave/full-wave), frequency modulation, frequency sweep |
| Platform size | 500*500mm |
| Table size | 500 × 500 × 450 automatic four-dimensional space all-in-one machine Shaker Table (up, down, left and right) (work on the same Countertop) |
| Vibration function (type) | ① Vertical ② Horizontal ③ Continuous action (vertical → horizontal or horizontal → vertical) ④ Random vibration (bandwidth can be set) ⑤ Vertical + horizontal (simultaneous vibration) ④ Sine wave (half wave/full wave) |
| FM function (arbitrarily adjust 1~ 600HZ) | Frequency range Any Frequency cannot exceed 1 of the following 2 items (Maximum Acceleration < 20g and Maximum amplitude < 5mm) |
| Sweep function (adjust 1~ 600HZ arbitrarily) | (Upper Frequency/Lower Frequency/Timer Range) Can be arbitrarily set to true standard back and forth frequency sweep |
| Programmable function (adjust 1~ 600HZ arbitrarily) | 1~ 15 segments, each segment can be set arbitrarily (Frequency/time) can be cycled |
| Frequency doubling function (adjust 1~ 600HZ arbitrarily) | 1 to 15 segments multiply ① low to high frequency ② high to low frequency ③ low to high and then to low frequency/recyclable |
| Logarithmic function/arbitrary adjustment 1~ 600HZ | ① down to the upper frequency ② up to the lower frequency ③ down to the upper frequency and then to the lower frequency --3 modes logarithmic/recyclable |
| sine wave | (Half wave/full wave)/Maximum sine wave excitation force 2000kgf |
| Precision | Display to 0.01Hz, precision 0.1Hz |
| Maximum test Weight | 100kg |
| Amplitude | 0~5mm |
| time control | Any time can be set (in seconds) |
| Power supply Voltage | 220V±20% |
| Maximum current | 10A |
| Vibrator Power | 2.2KW |
| Cooling mode | Natural air-cooled |
| Humidity range and noise | Temperature -10 ℃~ + 60 ℃/Humidity 10%~ 95%/Range/Noise 60 dB or less |
Packing list
whole machine X1, manual X1, certificate X1, warranty card X1, door-to-door installation X1
After-sales instructions
Warranty days: 540 days
