Specifications
| Pressure Accuracy | Full scale +/- 1% |
| Resolution | 0.01MPa(1psi) |
| Draw Rate Accuracy | +/- (2.5% + 0.3 seconds) |
| Resolution | 0.01MPa(1psi/s) |
| Kit diameter | 50mm |
| Range | 0.3~4MPa/50~580psi |
| pull rate range | 0.02 - 0.22MPa/s(2 - 32psi/s) |
| Dimensions | 260*100*66mm |
| Brake height | 85mm |
| Weight | 2.9Kg |
| Kit Weight | 6.1kg (13.5lb) |
| Power | 8 x AA NiMH/alkaline batteries (16 rechargeable batteries with charger) or AC mains (Model T only) |
| Battery life | 200 pulls per charge, up to 25MPa (3600psi) at 1MPa/sec (150psi/sec), Charging time < 5 hours |
Packing list
Host X1, 50mm forging die X6, 50mm forging die standard skirt cover X1, 50mm forging die cutting shaft X1, 50mm forging die cutter X1, Araldite standard two-component epoxy glue X2, grinding pad X1, shoulder strap X1, suitcase X1, AA rechargeable battery & charger X1, USB cable X1, CD X1, calibrate certificate X1, operation instructions X1
After-sales instructions
Warranty days: 365 days
1. If the instrument and equipment are not artificially caused by product quality problems, the manufacturer provides 1 year free warranty service;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32505/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
