Specifications
| Measurement range | 0~100°SR |
| Measurement Accuracy | 0.5SR |
| Vertical drain section | 137±1mm |
| DC diameter | 2.32±1mm |
| Overflow outlet discharge time | 149±1s |
| overflow path | 16.0±0.1mm |
| release control | Intelligent control, one-click completion |
| release method | Fully automatic release |
| Rising speed of cone | 100±10mm/s |
| Dimensions | 450*250*750mm |
| Weight | 50KG |
| meet the standard | ISO 5267/1、GB/T 3332-2004 |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32507/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
