Specifications
| Power supply Voltage | AC220V±10% 50HZ |
| Measurement range | 0~100N |
| Indication Precision | ±1% |
| Accuracy | 0.1N |
| Force resolution | 0.01N |
| Specimen length | Can be set within 50-200mm as needed (digital precise positioning) |
| Specimen width | 15, 25, 50mm three gears adjustable |
| stretching speed | 1~ 399 mm/min (digitally adjustable) |
| return speed | 1~ 399mm/min (can be adjusted digitally) |
| clamping air pressure | 0.4-0.6MPa |
| Instrument size (L * W * H) | 920*420*300mm |
| Net Weight | 65kg |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32780/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
