Specifications
| Power supply Voltage | AC220V±10% 50HZ |
| Force range | 50~5000N |
| Force resolution | 0.1N |
| Indication variability | ≤1% |
| Pressurization speed | 0~100mm/min |
| Test speed recommended | 12.5 +/- 2.5mm/min (Ring Pressure Test speed) |
| Plate parallelism | < (B/1000) mm B is the platen width |
| Plate size | 300*300mm |
| Working Travel | 300mm |
| Dimensions | 570*480*800mm |
| Net Weight | 85kg |
| Error of indication | ±1% |
Packing list
After-sales instructions
Warranty days: 365 days
