Specifications
| Measurement range | 0~4mm |
| Resolution | 0.001mm |
| Error of indication | ±0.0025mm/±0.5％ |
| Indication variability | ≤ 0.0025Mm or ≤ 0.5% |
| Measurement plane parallelism | ≤0.002mm |
| Contact area | 200±5mm² |
| Contact Pressure | 100±10kPa |
| Probe descent speed | ≤3mm/s |
| Dimensions | 400*360*520mm |
| Weight | About 25kg |
| Contact surface diameter | Φ16±0.5mm |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32805/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
