Specifications
| Measurement range | 5600kPa |
| Error of indication | ±0.5% |
| Resolution | 0.1kPa/1kPa |
| Oil delivery speed | 170±15mL/min |
| Film resistance | Raise 10mm, 170kPa~ 220kPa; Raise 18mm, 250kPa~ 350kPa |
| Clamping Force | ≤1200Kpa |
| Upper clamp ring aperture | Φ(31.5±0.05)mm |
| Lower clamp ring aperture | Φ(31.5±0.05)mm |
| Power supply Voltage | AC220V 3A 50Hz |
| Dimensions | 530*360*590mm |
| Weight | About 83Kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32847/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
