Specifications
| Force range | 20KN (2 tons) |
| Accuracy | ±1% |
| Force resolution | 1N |
| Deformation resolution | 0.1mm |
| Pressurization speed | 10mm/min |
| Test speed | 2mm/min |
| return speed | >200mm/min |
| Test space | 600*600*600mm |
| Plate parallelism | < 2/1000 × L, L is the length of the platen |
| Power supply Voltage | AC220V 10A 50Hz |
| Dimensions | 1000*650*1550mm |
| Weight | About 350kg |
| Working Travel | 600mm |
| Plate size | 600*600mm |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32850/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
