Specifications
| Pump maximum flow | 20L/min |
| Pump head type | double stage pump |
| Ultimate Vacuum | 15~20mbar |
| Maximum pump pressure | 1 bar |
| Vacuum adjustment | No vacuum regulating valve |
| interface specification | 10 mm |
| Pump head material | PTFE |
| Composite diaphragm material | PTFE composite diaphragm material |
| Disc material | FFPM |
| Duty Cycle | Can work continuously |
| Environment Relative Humidity | ＜80%RH |
| Medium and environment temperature | 5 ℃~40 ℃ |
| Motor rated speed | 1450RPM |
| Dimensions | 165*315*210mm |
| rated power | 120W |
| Power Supply | AC 220V 50HZ |
| Pump head material | PTFE |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32876/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
