Specifications
| Measurement range | 50~1600kPa |
| Clamping Force | ≥430Kpa |
| Error of indication | < 0.5% (within 0.3% measured) |
| Resolution | 1kPa |
| Oil delivery speed | 95±5mL/min |
| Film resistance | Raise 9mm, 30 +/- 5kPa |
| Upper clamp ring aperture | Φ(30.5±0.05)mm |
| Lower clamp ring aperture | Φ(33.1±0.05)mm |
| Power supply Voltage | AC220V 3A 50Hz |
| Dimensions | 530*360*590mm |
| Weight | About 83Kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32878/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
