Specifications
| Analysis | 1/100000 |
| Sampling Frequency | 400 times/second |
| Force Accuracy | +/- 0.1% of indication (20~100% FS) |
| Force Sensor type | 1mV/V,2mV/V,3mV/V,4mV/V,8mV/V,9.6mV/V |
| Applicable Force Sensors Range | 1~1000000N |
| extensometer resolution | 1/100000, sampling Frequency 50 times/sec |
| Extensometer Accuracy | +/- 0.1% of indication (20~100% FS) |
| Displacement resolution | Determined by the mechanical system and photoelectric encoder, it can generally reach 0.001mm. |
| Measurement Accuracy | Instrumentation system without error |
| Pressurization speed | 0.01~500mm/min |
| Speed Accuracy | Indication +/- 1% |
| force channel | Four. |
| Displacement channel | two |
| Power supply Voltage | 220±10%VAC 50Hz |
| pulse number range | 100~65535 |
| Unit switch | manter:kN/N/kgf/gf/t/Lbf、 :mm/cm/in |
| Operating temperature | 0~55°Ｃ |
| Relative Humidity | Not more than 80% |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/32916/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
