Specifications
| Lighting method | D/8 (Diffuse illumination, 8 ° direction reception) SCI meets standards CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | Φ40mm |
| Lighting source | Light spectrum LED Light source |
| spectroscopy | Plane grating spectroscopy |
| Sensor | Silicon photodiode array (dual row 24 groups) |
| Wavelength range | 400~700nm |
| wavelength interval | / |
| Light spectrum Bandwidth | 10nm |
| Reflectance Measurement Range | L: 0~100 reflectance: can test the reflectance at 3 specific wavelengths specified by the user (default 440nm, 550nm, 600nm) |
| Measurement caliber | Φ8mm |
| Light-containing method | SCI |
| Color Space | CIE LAB,XYZ,Yxy,LCh, |
| Color difference formula | ΔE*ab,ΔE*00 |
| Display Accuracy | Display 0.1, store 0.01 |
| Viewing Angle | CIE 10° |
| Available Light Sources | D65,A,F2(CWF) |
| display mode | Reflectance (user-specified reflectance at 3 specific wavelengths), sample chromatic value, color difference value/graph, pass/fail result, Color simulation, Color bias |
| Measurement time | About 1.5s |
| Repeatability of chromatic value | MAV/SCI,ΔE*ab 0.08以内 |
| Inter-instrument Agreement | ΔE*ab<0.4(MAV/SCI) |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| positioning method | Stabilizer positioning |
| Dimensions | 81*71*214mm |
| Weight | Approx. 500g |
| Battery life | Lithium battery, 6000 cycles in 8 hours |
| Lighting source life | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Interface | USB |
| data storage | 500 master standards and 10,000 samples |
| Operating language | Simplified Chinese, English, Traditional Chinese |
| Operating environment | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
Packing list
host X1, data cable X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
