Specifications
| Lighting method | D/8 (diffuse illumination, 8 ° direction reception) SCI/SCE measurement conforms to CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | Φ40mm |
| Lighting source | Light spectrum LED Light source |
| spectroscopy | Plane grating spectroscopy |
| Sensor | Silicon photodiode array (dual row 32 groups) |
| Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Light spectrum Bandwidth | 10nm |
| Reflectance Measurement Range | L: 0~120 reflectance: 0~200% |
| Measurement caliber | Single diameter: Should 8mm/Should 10mm |
| Light-containing method | Simultaneous testing of SCI/SCE |
| Color Space | CIE LAB,XYZ,Yxy,LCh,s-RGB,βxy,Munsell(C/2) |
| Color difference formula | ΔE*ab,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99 |
| Chroma indicator | WI, YI, homochromatic index MI colour fastness, discoloration fastness, force, coverage, Formula Guide |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | D65,A,C,D50,F2(CWF),F7(DLF),F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum graphs/data, sample chromatic values, color difference values/graphs, pass/fail results, Color simulation, Color bias |
| Measurement time | Approximately 1.5 seconds (approximately 3.2 seconds for simultaneous SCI/SCE testing) |
| Repeatability of chromatic value | MAV/SCI,ΔE*ab 0.06以内 |
| Inter-instrument Agreement | ΔE*ab<0.3(MAV/SCI) |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| positioning method | Camera positioning, stabilizer positioning |
| Dimensions | 81*71*214mm |
| Weight | Approx. 500g |
| Battery life | Lithium battery, 6000 cycles in 8 hours |
| Lighting source life | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Interface | USB |
| data storage | 1000 master standards, 20,000 samples (one data can include SCI/SCE at the same time) |
| Operating language | Simplified Chinese, English, Traditional Chinese |
| Operating environment | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
Packing list
host X1, data cable X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
