Specifications
| Camera system | Professional CCD Digital Camera + High Performance Microscope |
| Maximum resolution | 1280×1024 |
| How to take pictures | Single sheet, continuous |
| meet the standard | ASTM D 724、ASTM D 5946、ISO15969 |
| Light source | LED Cold Light source with continuously adjustable luminance, uniform emission, clearer image contour and higher resolution |
| Contact angle analysis method | 0/2 method, tangent method, can be calculated automatically or manually (corrected) |
| Contact angle Measurement Range | 0~180° |
| Contact angle test resolution | 0.01° |
| Solid surface energy | Calculation of Surface Energy, Droplet Volume and Solid Adhesion by One Liquid Method and Two Liquid Method |
| Surface tension test method | without |
| Surface tension Measurement Range | without |
| Surface tension test resolution | without |
| Sample stage displacement | Front and rear: 60mm; left and right 35mm; up and down 50mm, the sample stage can be adjusted horizontally, and the diameter is 90mm. |
| Sample Stage Size | 105×120mm |
| Maximum sample thickness | ≤35mm |
| Tilt platform | without |
| Injection method | Manual Sample injector |
| Dimensions | 525*160*470mm |
| Net Weight | 12Kg |
| Power | 220V/50Hz |
| Power | 0.2KW |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
