Specifications
| Power supply Voltage | AC220V±10% 50HZ |
| Measurement range | 50~1600kPa |
| Error of indication | ±0.5%F.S |
| Oil delivery speed | 95±5mL/min |
| Clamping Force | ≥430Kpa |
| Film resistance | Raise 9mm, 30 +/- 5kPa |
| System sealing | At the upper limit of measurement, 1 minute pressure drop < 10% Pmax |
| Upper clamp ring aperture | Φ(31.5±0.05)mm |
| Dimensions | 480*420*600mm |
| Net Weight | 65kg |
| Lower clamp ring aperture | Φ(31.5±0.05)mm |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33086/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
