Specifications
| Power supply Voltage | AC220V±10% 50HZ |
| Measurement range | 200~5600kPa |
| Error of indication | ±0.5%F.S |
| Oil delivery speed | 170±15mL/min |
| Clamping Force | ≥700Kpa |
| Film resistance | Raise 10mm, 170kPa~ 220kPa; Raise 18mm, 250kPa~ 350kPa |
| System sealing | At the upper limit of measurement, 1 minute pressure drop < 10% Pmax |
| Upper clamp ring aperture | Φ(31.5±0.05)mm |
| Dimensions | 480*420*600mm |
| Net Weight | 65kg |
| Lower clamp ring aperture | Φ(31.5±0.05)mm |
Packing list
After-sales instructions
Warranty days: 365 days
