Specifications
| Power supply Voltage | AC220V±10% 50HZ |
| Measurement range | 0~300N |
| Indication Precision | ±1% |
| stretching speed | 1~ 399 mm/min (digitally adjustable) |
| return speed | 1~ 399mm/min (can be adjusted digitally) |
| Clamping Force | 0.2Mpa~ 0.4Mpa Pneumatic blessing |
| Specimen size | Arbitrary adjustment within the range of 0-200mm |
| Instrument size | 450mm*550mm*1200mm |
| Net Weight | 55kg |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33090/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
