Specifications
| structural form | single arm |
| Maximum test force | 2KN |
| Test force Measurement Range | 1% to 100% FS (full scale) |
| Test force indication relative error | +/- 1% or +/- 5% of the indication |
| Deformation Measurement Range | 2~100%FS |
| Test speed range | 0.1~500mm/min |
| Effective stretch length | Not less than 650mm |
| Power supply power | 220V、0.8kw |
| Dimensions | 400*300*1200mm |
| Weight | Approx. 80kg |
| Operating Environment | Room temperature~ 30 ℃, Relative Humidity does not exceed 80% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33101/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
