Specifications
| Display | Touch screen liquid crystal display |
| induction method | pressure converter |
| Instruction method | Digital KG, MPA units can be converted |
| resolution | 1kPa |
| Accuracy | ±0.5%FS |
| Capacity | 250 ~ 5600kPa |
| Clamp ring diameter | ∮31.5mm |
| Clamping indication | Pressure gauge (set Clamping Force) |
| hydraulic oil | Glycerin 85%, distillation water 15% |
| Oil delivery speed | 170±10cc/min |
| Clamping Force | ≥ 690Kpa |
| motor | Shockproof motor 1/4 HP |
| Dimensions | 620*510*570mm |
| Weight | 67Kg |
| Power | 1∮，AC220V，2.6A |
| printout | With print |
| Random delivery | Rubber film (2 pieces), aluminum foil (5 pieces), glycerin (1 bottle), special wrench (1 piece) |
Packing list
Host X1, rubber film X2, aluminum foil X5, glycerin X1, special wrench X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33116/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
