Specifications
| Measurement range | 0~5mm |
| Resolution | 0.001mm |
| Indication of variability | ≤ 0.002mm or ≤ 0.5% |
| Measurement plane parallelism | ≤0.001mm |
| Measurement speed | 1mm/s~60mm/s (adjustable) |
| Regulator time | Adjustable from 0.1 to 5seconds |
| Number of continuous measurements | 1~ 99 times optional |
| Contact area | 200 +/- 5mm ², Chassis boss diameter (16 +/- 0.15) mm |
| Contact Pressure | 100 ± 10kPa |
| Probe descent speed | 0.5 ~ 10mm / s, TAPPI (1.0 ± 0.3mm / s) () |
| Display | 7.0In touch screen control. |
| Print function | Built-in silent high-speed thermal printer with its own printing function |
| Operating Environment | Temperature 10~35 ℃, Relative Humidity does not exceed 85% |
| Dimensions | 330*350*500mm |
| Weight | 25kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33122/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
