Specifications
| Sampling size | 340*320*5mm |
| Sampling thickness | 0~5mm |
| Parallel Accuracy | 0.1±0.01mm |
| Upper blade thickness | 7.5mm |
| Lower blade thickness | 11mm |
| knife length | 640mm |
| positioning torque ratio | 31:11 |
| Feed height | 5mm |
| Blade Hardness | Blades can be used to cut steel sheets |
| Parallel positioning | Inlet linear slide |
| ruler | Triangular inclined surface ruler, reverse reading |
| Guide height | 1mm |
| notch parallelism | ≤0.1mm |
| Sampling table panel material | 304 stainless steel |
| Dimensions | 700*500*190mm |
| Weight | About 25kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
