Specifications
| Force range | 0~3000N |
| Error of indication | ≤±1% |
| Test force test range | 0.4%~100%FS |
| Working Travel | 1~80mm |
| Force Accuracy | ≤±1% |
| Force resolution | 0.01N |
| Deformation resolution | ≤0.1mm |
| Up and down platen parallelism | ≤0.05mm |
| Pressurization speed | 12.5±1mm/min |
| transverse pressure bearing | 71*21mm/10000N |
| longitudinal pressure bearing | R=20.5mm/2/10000N |
| Axial departure protection | Brass Seat Sleeve/Stainless Steel Hardened Lifting Shaft |
| System Power Supply | Solid State Power Supply |
| test function | Side pressure, ring pressure, gluing, flat pressure, micro compression |
| Human Machine Interface | 7Inch touch screen, with data processing function, optional R232 computer connection software |
| printout | modular integrated thermal printer |
| Dimensions | 420*400*500mm |
| Net Weight | 42kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
