Specifications
| Measurement range | 10~1400kpa |
| Precision | ≤±0.3% |
| Resolution | 0.01kpa |
| deformation error | ≤0.25mm |
| Concentricity of Upper/Lower plates | ≤0.15mm |
| Film resistance | (9±0.2)mm /（30±5)kPa |
| Oil delivery speed | 95±5mL/min |
| Pressure outer diameter | 35mm±1mm |
| work displacement | 53mm±2mm |
| deformation monitoring | full window observation |
| platen diameter | Upper plate diameter: 30.5 +/- 0.1mm, lower plate diameter: 33.1 +/- 0.1mm |
| Measurement head control | Intelligent control pressure relief system |
| System Power Supply | Solid State Power Supply |
| clamping positioning | 360 ° free orientation positioning test head |
| positioning area | 65.313cm² |
| Clamping Force | 0~1200Kpa |
| Display | 7Inch touch screen + button test |
| unit conversion | kg/cm2、kpa、lbf/in2 |
| printout | modular integrated thermal printer |
| Dimensions | 420*400*500mm |
| Weight | About 38Kg |
| Operating Environment | Temperature (20 +/- 10) ℃, Humidity < 85% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
