Specifications
| Measurement range | 10 ~ 1600kpa |
| Accuracy | ≤±0.3% |
| Resolution | 0.01kpa |
| deformation error | ≤0.25mm |
| Concentricity of Upper/Lower plates | ≤0.15mm |
| Film resistance | (9±0.2)mm /（30±5)kPa |
| Oil delivery speed | 95±5mL/min |
| Pressure outer diameter | 35mm±1mm |
| Work displacement | 53mm±2mm |
| Deformation monitoring | Full window observation |
| Pressure plate diameter | Upper plate diameter: 30.5 +/- 0.1mm, lower plate diameter: 33.1 +/- 0.1mm |
| Measurement head control | Intelligent control pressure relief system |
| System Power | Solid State Power |
| Clamping positioning | 360 ° free orientation positioning test head |
| positioning area | 65.313cm² |
| Clamping Force | 0 ~ 1200Kpa |
| Display | 7Inch touch screen + button test |
| unit conversion | kg / cm2 、 kpa 、 lbf / in2 |
| printout | Modular integrated thermal printer |
| Dimensions | 420*400*500mm |
| Weight | About 38Kg |
| Operating Environment | Temperature (20 +/- 10) ℃, humidity < 85% |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33130/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
