Specifications
| Specimen size | 25.4*128mm |
| Specimen size | 25.4*25.4mm |
| Maximum sampling thickness | 1.2mm |
| Common sample pressure | (690±21)kpa (1034±34)kpa |
| Sample holding force | 0~400N (adjustable) |
| Sample pressure range | 0~65kg/cm²（0~950psi） |
| Primary pressure area | 12.72cm² |
| Parallel positioning of specimen holder | R=0.4×10 |
| Pressure arm ratio | 231.08：0.8 |
| release method | Fully automatic release |
| Impact Angle | 90° |
| Resolution | 0.001Lbf/in ², 5000 pulse high-precision encoder |
| Double-sided adhesive force | >486N/m |
| Measurement range | A档：(0~500)J/m²；B档：(500~1000)J/m²；C档：(1000~1500)J/m² |
| Self-calibrating | Dedicated 5-level calibrated tool set (additional) |
| Error of indication | A档：±1J/m²；B档：±2J/m² |
| unit | J/M²、lbf/in² |
| Display | 3.2In LCD display, real-time display of test data |
| software | Optional computer connection software, office document processing documents, end point A4 printing |
| printout | modular integrated thermal printer |
| Dimensions | 500*400*650mm |
| Weight | 70KG |
| number of samples | Group of 5 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
