Specifications
| Measurement range | A: （ 50 ~ 8000 ） mN 、 B: （ 8000 ~ 16000 ） mN |
| Tear arm | 104±1mm |
| tearing initial angle | 27.5±0.5° |
| tear distance | 43±0.5mm |
| incision length | 20mm |
| Longitudinal displacement of incision | 8mm |
| Paper surface size | 25*15mm |
| Maximum clamping area | 6.48cm2 |
| clamping torque ratio | 2.2:0.7 |
| number of free pendulums | min≥20，mid≥25,stand≥35. |
| Specimen size | (63±0.5)mm*(50±2)mm |
| Cutter arm ratio | 14：5.5 |
| tear migration | Less than the edge extension wire 10mm |
| Distance between clamps | 2.8±0.3mm |
| Human Machine Interface | 3.2In LCD display, modular integrated thermal function |
| Dimensions | 450*380*550mm |
| Weight | About 30kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
