Specifications
| Measurement range | 10~1000mN |
| Test speed | 1.2mm/s |
| Probe total travel | 12mm |
| Measurement time | 15s |
| Indication resolution | 1mN |
| Precision | ±1% |
| Indication variability | ≤1% |
| Probe indentation depth | 8+0.5mm |
| Probe width | 400±0.5mm |
| Specimen table slot-die width | 5mm、6.35mm、10mm、20mm、30mm(订配) |
| test leverage | 32:73 |
| Moment group | 20/25 group, 10/16 group, 6.35/16 group, 5/16 group |
| Test Weight | 200g、400g、600g |
| Sample table slot-die parallelism error on both sides | ≤0.05mm |
| show | 3.5In LCD with Linear dispersion display |
| printout | Comes with a micro thermal printer |
| Dimensions | 570*415*200mm |
| Weight | About 30kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33142/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
