Specifications
| Differential pressure range | 1~ 4000Pa (nozzle), 1~ 1000Pa (sample) |
| transmission rate | 0.2~30000mm/s |
| Unit selection | mm/s、m3/m2･min、 cm3/cm2･s、m3/m2･h、cfm、L/dm2･min、L/m2･s |
| transmission rate | 0.1~12000mm/s |
| Measurement error | ≤±2% |
| Specimen thickness | ≤15mm |
| Adjustment of air intake | Data feedback dynamic adjustment |
| test area | 5cm2；20cm2；50cm2；100cm2 |
| Specimen diameter constant circle | Ф50mm（≈19.6cm2）Ф70mm（≈38.5cm2） |
| nozzle | 10 in total |
| Data processing | ≤ 5000 tests |
| Data output | modular integrated thermal printer |
| interface | bidirectional test function |
| Power Supply | AC 220V±10V |
| power consumption | 2000W |
| Dimensions | 550*650*1100mm |
| Weight | 100kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33144/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
