Specifications
| Working speed | 4.5rpm |
| Temperature Resolution | 1°C |
| Temperature measurement Accuracy | Level 0.5 +/- 1 word |
| Temperature adjustable range | RT+~200°C |
| Adjustable range of working pressure | 49~108N |
| Standard operating temperature | 175±8℃ |
| Temperature safety | With over-temperature protection device, the shell temperature does not exceed 50 ℃ after the working time exceeds 2 hours. |
| heating mechanism | The thermal insulation resistance value of the electric heating plate should be greater than 5MΩ |
| Real-time monitoring window | 155 × 338mm, can be opened at any time to monitor the real-time working status |
| Environment temperature | 20 +/- 10 ℃, no vibration, no flammable, corrosive gas |
| Gear tooth form | A-tooth |
| Grooved wheel outer diameter | 228.5±0.5mm |
| Film thickness | 16±1mm |
| number of teeth | 84 |
| crest radius | R1.50±0.1mm |
| Valley radius | R2.0±0.1mm |
| tooth height | 4.75±0.05mm |
| Power | AC220V，50Hz |
| Weight | 53kg |
| Dimensions | 520*450*380mm |
| speed error | ±0.5RPM |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33153/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
