Specifications
| Rotation speed | 4.5R/min, the error should not exceed +/- 0.5r/min |
| Display resolution | 1℃ |
| Measurement Accuracy | Level 0.5 +/- 1 Word |
| Operating temperature adjustable range | Room temperature~ 200 ℃ (according to different paper types and Working pressure selection) |
| Working pressure adjustable range | (4~ 108) N, the set Working pressure should be consistent with the actual Working pressure of the flute wheel, and the error should not exceed +/- 10%. |
| Operating temperature | 175 ℃, 177 ℃ when the actual error should not exceed 8 ℃ |
| Temperature safety | Working time exceeds 2 hours, the shell temperature does not exceed 50 ℃. |
| heating mechanism | The thermal insulation resistance of the electric heating plate should be greater than 5MΩ. |
| real-time monitoring window | With monitoring window 155 × 338mm, it can be opened at any time to monitor the real-time working status |
| Environmental temperature | Environmental temperature 20 +/- 10 ℃; no vibration, no flammable, corrosion gas |
| Standard tooth type | A-tooth |
| Grooved wheel outer diameter | 228.5±0.5mm |
| Flute wheel thickness | 16±1mm |
| number of teeth | 84. |
| Tooth tip arc radius | R l.5±0.1mm |
| Valley arc radius | R 2.0±0.1mm |
| Full tooth height | 4.75±0.05 mm |
| Power supply Voltage | AC220V 50Hz |
| Dimensions | 520*450*380mm |
| CCT clamp tooth length | Greater than 19mm |
| CCT clamp number of teeth | 16. |
| CMT clamp tooth depth | 4.75±0.05mm |
| CMT clamp lower tooth radius | 2.4±0.1mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
