Specifications
| Force range | 0~3000N |
| Error of indication | ≤±1% |
| Test force test range | 0.4%~100%FS |
| Working Travel | 1~80mm |
| Force Accuracy | ≤±1% |
| Force resolution | 0.01N |
| Deformation resolution | ≤0.1mm |
| Up and down platen parallelism | ≤0.05mm |
| Pressurization speed | 12.5±1mm/min |
| transverse pressure bearing | 71*21mm/10000N |
| longitudinal pressure bearing | R=20.5mm/2/10000N |
| Axial departure protection | Brass Seat Sleeve/Stainless Steel Hardened Lifting Shaft |
| test function | Side pressure, ring pressure, gluing, flat pressure, micro compression |
| Human Machine Interface | 7Inch touch screen with data processing function, |
| software | R232 computer connection software (optional) |
| printout | modular integrated thermal printer |
| Dimensions | 420*400*500mm |
| Weight | About 42kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33155/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
