Specifications
| Measurement range | 150~5600kpa |
| Precision | ≤±0.5% |
| Resolution | 0.01kpa |
| deformation error | ≤0.5mm |
| Concentricity of Upper/Lower plates | ≤0.25mm |
| Film resistance | 10mm, (170~220)kPa18mm, (250~350)kPa |
| Oil delivery speed | 175±5mL/min |
| Pressure outer diameter | 35mm±1mm |
| work displacement | 53mm±2mm |
| drive structure | All Steel Chain Drive Improves Stability and Life |
| deformation monitoring | Chord length 41mm three-dimensional semicircle full window observation |
| platen diameter | Upper plate diameter: 30.5 +/- 0.1mm, lower plate diameter: 33.1 +/- 0.1mm |
| Measurement head control | Intelligent control pressure relief system |
| System Power Supply | Solid State Power Supply |
| clamping positioning | 360 ° free orientation positioning test head |
| positioning area | 65.313cm² |
| Clamping Force | 0~1000Kpa |
| Display | 7Inch touch screen + button test |
| printout | modular integrated thermal printer |
| Dimensions | 420*400*500mm |
| Weight | About 45Kg |
| Operating Environment | Temperature (20 +/- 10) ℃, Humidity < 85% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33157/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
